Function point
1.Controlled with six or seven axes: wire feed axis, pitch axis, upper variable diameter lower variable diameter, upper cutter axis,lower cutter axis and core pulling axis.
2.The six axes can work single-step or synchronously.
3.Computer interface displayed in Chinese and English which makes the operation easy.
4.Equipped with right and left rotation cutter frame.
5.Cutter can perform straight cut, opposite cut, twist cut and swing cut.
6.Computer has automatic programming functions.
Mian Technique Parameter
|
Style |
TK-790 |
|
Number of Axes |
Six-seven axes (wire feed axis, pitch axis, upper variable diameter, lower variable diameter, upper cutter axis, lower cutter axis and core pulling axis) |
|
Wire diameter (Carbon steel wire) (mm) |
φ3〜φ9 |
|
Total power(kw) |
97 |
|
Oil Quenching Line≤1700 |
≤φ8 |
|
Max. Outside Diameter(mm) |
φ120 |
|
Wire Feed Length |
No Limitation |
|
Wire Feed Speed(m/min) |
105 |
|
Rotation |
Left or Right |
|
Forming Way |
Double Points |
|
Number of Wire Feed Axes |
4Pairs |
|
Variable Diameter Axis Motor (kw) |
8×2 |
|
Pitch Axis Motor(kw) |
8 |
|
Wire Feed Axis Motor(kw) |
20×5 |
|
Cutter motor(kw) |
15×2 |
|
Core Pulling Motor(kw) |
1.8(Standard) |
|
Machine working state size(LxWxH) |
2650x2800x2250 |
|
Main Host Weight(kg) |
6500 |
|
Voltage |
3AC 380V/50HZ |
Applicable Spring
