Product Description
Features
●Body Alignment: The body can be aligned by a cam activated support tool that pushes out the end.
●Initial Tension: This is controlled by the depth of the cam activated coiling tool.
●Straight Leg Formation: It can be done by moving the coil tool up and down.
●Two types of cut off: Rotational cutting and mandrel cut.
●Turn control: Magnetic touch sensor controls the number of turns precisely.
●Four step separator: Assures precision intermittent motion at high speeds.
●Two grips: One grips over the body portion. The other is to insert a blade between the coils.
●Synchronous bending: Bending both ends synchronously will give accurate end angles.
●Automatic selection: Two sensors inspect both hooks and sort for good and bad springs.
●Automatic stop functions for safety operation by preset counter, decoiler fail, invalid cut,magnetic touch and bad spring counter.
